HAICO High-Speed Treadmills – 4000 and 5000

SEVERAL ADVANTAGES FOR TRAINING, REHABILITATION, RESEARCH AND DIAGNOSING

Ideal tool for professional trainers with race horses

No weather restrictions
Control of speed, distance, uphill and much more
Reduced impact to legs – running surface of Haico treadmills matches to turf – no hoof problems
Increases muscular power and quality of gaits
Horses work willingly on treadmill due to very low construction and silent structure
More horses can be trained in a shorter period of time
Conditioning can be started as early as 6 months of age
Gait can be followed accurately at any time and running speed
Diagnosing of lameness
Performance testing with Haico SH standard exercise test (SET) and Competition exercise test (CET) or individual tests, full possibility for programming
Optional automatic run or manual run
Optional automatic pulling load unit for increased stress
All functions can be controlled either manually or automatically via Touch Screen control unit
No service or oiling points makes using easy and trouble free
Wide range of safety equipment for secure using as standard
No large space requirements and long life time

Technical details

– Treadmill technical details

And for veterinarians

Controlled environment for evaluating lameness
Observations and filming of horse gait
Endoscope and heart functioning under controlled stress
Oxygen and CO2 examination
Performance testing with Haico SH Standard exercise test and Competition exercise test (CET) or individual tests, full possibility for programming
No large space requirements
Fast acceptance of horses due to very low and silent structure
High level of reproducibility of trials
Safe and easy to use

Downloads

– More comfort – less vibration and noise
– Control unit – clear and logical using
– Haico treadmill advantages
– Haico treadmill controlling
– Hygiene of treadmill
– Running surface curve
– Safety harness
– Standard test
– Treadmill leaflet
– Wireless remote control

Extra equipment

– Air blower
– Heart rate monitoring
– Pulling load unit
– Working platform

Researches have established that a very high similarity exists between the surfaces found in nature grass and that of the Haico treadmill. The naturelike surface doesn’t strain the horses legs even in strenuous training. Haico Treadmill selection consists of two standard models. Both treadmills are designed for high speed training. They offer the following advantages:

Measures

Low running surface height allows installation on the floor.

Performance

Service free low-friction belt structure. Separate cooling inside the treadmill enables continued use. Compact, steplessly adjustable weigth unit inside the structure. Contrary wind blower follows the speed of the belt.

Safety and comfort

Soundproof compact structure. Totally isoleted frame from the floor by rubber pads. Dung is hurled automatically away from the back. No oiling points.

Adjustability

Adjustable width of the safety rails, horse stays safely in the middle of the belt.

Measures	Model 4000	Model 5000
Length without ramps	4500 mm	5500 mm
Length with ramps	6500 mm	7500 mm
Weight	2000 kg	2400 kg
Running surface	1,15 m x 4,1 m	1,15 m x 5,1 m
Height of the running surface	370 mm	370 mm
Speed range	0-54 km/h	0-54 km/h
